Convert from HDMI to 12G-SDI. Works with all video formats including SD, HD, 6G and 12G-SDI rates and includes an up converter for converting HD to Ultra HD. Embed audio from balanced analog or AES/EBU and timecode input. Ideal for converting HDMI consumer cameras to SDI, or adding SDI outputs to computers with HDMI connections.
Download Manual Download Software$545
2 x 12G SDI outputs. Automatically matches the SD, HD and 12G-SDI HDMI video input.
Please click here for a summary of recommended cables to use with Blackmagic 12G‑SDI products.1 x HDMI 2.0 type A.
2 channels professional balanced analog audio via XLR connectors. Right XLR can be configured for timecode input.
4 channels professional 110Ω balanced digital audio via XLR connectors. Right XLR can be configured for Timecode input.
16 channels.
Automatic switching between SD/HD/2K and 4K.
USB or Ethernet.
Yes
525i59.94 NTSC, 625i50 PAL
720p50, 720p59.94, 720p60
1080i50, 1080i59.94, 1080i60
1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p47.95, 1080p48, 1080p50, 1080p59.94, 1080p60
2Kp23.98 DCI, 2Kp24 DCI, 2Kp25 DCI
2160p23.98, 2160p24, 2160p25, 2160p29.97, 2160p30, 2160p47.95, 2160p48, 2160p50, 2160p59.94, 2160p60
4Kp23.98 DCI, 4Kp24 DCI, 4Kp25 DCI
SMPTE 259M, SMPTE 292M, SMPTE 296M, SMPTE 372M, SMPTE 424M, SMPTE 425M level A and B, SMPTE 2081‑1, SMPTE 2081‑10, SMPTE 2082‑1 and SMPTE 2082‑10
SDI video connections are auto switching between standard definition SDI, high definition 3G-SDI, 6G-SDI, and 12G-SDI.
4:2:2
Television standard sample rate of 48 kHz and 24-bit.
4:2:2
YUV
525i59.94 NTSC, 625i50 PAL
720p50, 720p59.94, 720p60
1080i50, 1080i59.94, 1080i60
1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p47.95, 1080p48, 1080p50, 1080p59.94, 1080p60
2Kp23.98 DCI, 2Kp24 DCI, 2Kp25 DCI
2160p23.98, 2160p24, 2160p25, 2160p29.97, 2160p30, 2160p47.95, 2160p48, 2160p50, 2160p59.94, 2160p60
4Kp23.98 DCI, 4Kp24 DCI, 4Kp25 DCI
REC 601, REC 709
YUV 4:2:2 in HD, 2K and 4K.
HDMI input is unable to capture from copy protected HDMI sources. Always confirm copyright ownership before capture or distribution of content.
HD up and down conversion
Mac™ and Windows™ software upgrade via USB and Ethernet.
Via included updater application.
Mac 10.15 Catalina,
Mac 11.1 Big Sur or later.
Windows 10, 64-bit.
Mini Switches, USB and Ethernet via free software utility.
Front mounted Smart Panel with LCD, rotary knob and six settings buttons.
1 x built in international AC power supply with IEC C14 inlet. IEC Power cable required. 100 - 240V AC Input.
Can be powered via 48V DC using PoE+ (power over ethernet).
16 Watts
100 - 240V AC
0° to 40°C (32° to 104°F)
-20° to 60°C (-4° to 140°F)
0% to 90% non‑condensing
Teranex Mini HDMI to SDI 12G
Welcome wallet with QR code for software download
3 year Limited Manufacturer’s Warranty.
